- Brand: Perkins Lovol
- Cylinder No.: 6 cylinder
- Cooling way: Water cooled
- Combustion system: Direct injection
- Displacement: 5.99L
- Usage: Water pump
Advantages
1 The engine can be easily started without the help of pre-heater at the temperature of -10°C,and with the cold start aid at the temperature of -25°C.
2 With the radiator and independent fan drive , the engine can work well at an environmental temperature of 50°C .
3 The instrument control box with the function of high water temperature, low oil pressure and over-speed alarming stop, makes more convenient and reliable operation .
4 Convenient for the customers’ own installation, the air cleaner, radiator and under frame can be followed to assemble. And also the clutch can be applied according to the need of the customer
Engine Model |
1006-6TZ |
|
Number of Cylinders |
6 |
|
Model Information |
Four Stroke, Liquid Cooled, Vertical Inline, Direct Injection, Dry Liner |
|
Induction system |
Turbocharged |
|
Bore x Stroke (mm) |
100×127 |
|
Displacement (L) |
5.99 |
|
Compression Ratio |
17.5:1 |
|
Rated power |
1500r/min |
84 |
1800r/min |
95 |
|
2200r/min |
100 |
|
Governing rate |
≤10% |
|
Net weight(kg) |
780 |
|
Electrical system |
24V(12V optional) |
|
Dimensions LxWxH (mm) |
1520×708×1100 |
